Specifications

Motherboard

Mini ITX, µATX, ATX, eATX, SSI EEB

Drive Bays

20x 2.5" or 3.5" Hot-Swap

1x drive bay Slim DVD for 1x Slim DVD or 1x 2.5"

internal hard drive

2x drive bays 3.5" for 1x 3.5" or 1x 2.5" internal

hard drive

Front Connectors

USB 2.0: 2

Cooling System

Internal: 4x 120mm

(included, Molex connector)

Rear: 2x 80mm

(included, 3pin connector)

Controls

Power-Button

Reset-Button

LED

Power

HDD Activity

3x Network Activity

Alert

Power Supply

ATX / Redundant PSU

Material

1.0/1.2mm Steel

Packing Units

Shipping Unit: 1 piece

Pallet: 12 pieces

Guarantee and Warranty

Case 24 Months Warranty

Article Number

EAN-Code

88887121

4260133126428

Scope of Delivery

Screw set

Mounting bracket for ATX (preassembled), 4HU

redundant and 3HU triple redundant PSU

Adapter for 2HU PSU + optional 80mm fan bracket

Mounting bracket for diverse PSU

Assembly tool

Features

3x 120mm and 2x 80mm fan included

Drive brackets removable

USB 2.0 as block connector

Reusable and perforated slot bracket

(rear)

Lid with snap lock

S-ATA/SAS Hot-Swap backplane with SFF-8087 socket¹

Optional Accessories

Lockable frontgrill 4HU silver

(Article number: 88887142)

¹ The backplane is only compatible with a SAS-Controller with SFF-8087 connector.

In operation with SATA-Controllers, please order the optional SFF8087 cross-over cables (Art.-No.: 88885237) in right quantity.

Dimensions and Weight

Cage

Case

Package

Height

178mm

240mm

Width

433mm

482mm

560mm

Depth

650mm

690mm

830mm

Weight (net): 15.1 kg

Weight (gross): 18.00 kg

Errors excepted. No warranty for the correctness of the information State: 26.09.2014

Certification:

Power Supply

Connector

Quantity

Max. Length

Mainboard 20+4Pin

P4 12V 4Pin

P4/EPS 4+4Pin

P8 12V 8Pin

PCI-Express 6+2Pin

PCI-Express 6Pin

IDE 4Pin

S-ATA

Floppy

RPM sensor cable

Fan Control

Fan: 120mm

1 2

Certification: 2
